8566 Punch Pin
8566 Punch Pin is a durable tooling solution designed for high-load stamping and forming tasks. It delivers stable performance in continuous production environments where strength and reliability are essential. Manufactured from advanced tool steel, it ensures consistent operation under impact conditions. Suitable for industrial applications, it supports accurate processing, improved efficiency, and long-term manufacturing stability.
- Load Bearing Capacity: Handles extreme stamping pressure effectively.
- Material Stability: Maintains properties under repeated stress cycles.
- Edge Durability: Resists chipping during continuous operation.
- Operational Reliability: Ensures steady performance in production lines.
Product Description
Introduction
8566 Punch Pin is a high-strength tooling component manufactured from premium 8566 tool steel, designed for demanding stamping die and metal forming applications. It is widely used in progressive dies and heavy-duty punching systems where excellent toughness, impact resistance, and stable cutting performance are required. Compared with conventional tool steels, 8566 material provides improved durability and fracture resistance, making it suitable for long-term industrial production environments.
Through advanced CNC machining, precision grinding, EDM processing, and vacuum heat treatment, 8566 Punch Pin achieves high dimensional accuracy and stable mechanical properties. Tight tolerances up to ±0.002 mm ensure consistent punching performance in continuous and high-load operations. The optimized material structure delivers a balanced combination of hardness and toughness, allowing the punch to withstand repeated impact without deformation or edge failure.
8566 Punch Pin is widely applied in automotive manufacturing, precision hardware, electronics, connectors, terminals, and sheet metal fabrication industries. It is suitable for various stamping processes including punching, forming, and piercing of metal components. Custom options such as diameter, length, head design, and surface coatings like TiN or TiCN can be produced according to customer requirements. This flexibility makes it a reliable solution for OEM tooling, non-standard dies, and high-strength industrial manufacturing applications.
Specifications
| Item | Description |
|---|---|
| Product Name | 8566 Punch Pin |
| Material | 8566 Tool Steel |
| Hardness | HRC 58–64 |
| Tolerance | ±0.002 mm |
| Diameter Range | Customized |
| Length Range | Customized |
| Surface Finish | Precision Ground |
| Heat Treatment | Vacuum Heat Treated |
| Manufacturing Process | CNC Machining + Grinding + EDM |
| Customization | OEM / ODM Available |
