Automotive Mold Guide Bushing
Automotive Mold Guide Bushing is a guiding element used in automotive tooling systems to support precise movement of mold components. It ensures consistent alignment between guide pillars and mold structures during repeated operation. Designed for durability and stable performance, it helps improve production reliability in automotive manufacturing environments with demanding cycle requirements and strict quality standards.
- Improved Load Balance Efficiency: distributes pressure evenly across surfaces
- Reduced Operational Friction Heat: limits heat generation during movement
- Stable Long Cycle Endurance: maintains function over extended production runs
- Enhanced Surface Contact Control: improves smoothness between mating parts
Product Description
Introduction
Automotive Mold Guide Bushing is a precision component used in automotive mold systems to ensure accurate alignment between guide pillars and mold plates. It supports stable guiding movement during repeated mold opening and closing cycles, reducing friction and preventing positional deviation. This helps maintain consistent dimensional accuracy and high-quality output in automotive parts manufacturing.
The product is manufactured from high-grade materials such as bearing steel, alloy steel, or bronze, followed by heat treatment and precision grinding processes. These manufacturing steps ensure high hardness, excellent wear resistance, and stable mechanical performance under continuous high-load conditions. The finely finished inner surface allows smooth sliding performance, even in high-speed and long-cycle production environments.
Automotive Mold Guide Bushing is widely applied in automotive interior and exterior plastic parts molds, bumper and trim molds, lighting component molds, electronic housings, and precision stamping dies. It is also used in automated production systems for vehicle components. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can be customized according to drawings or special requirements. With reliable performance and long service life, it is an essential part for improving mold efficiency, reducing maintenance costs, and ensuring stable automotive production quality.
Specifications
| Item | Description |
|---|---|
| Product Name | Automotive Mold Guide Bushing |
| Material | SUJ2, GCr15, SKD11, Bronze |
| Hardness | HRC 58–62 |
| Surface Treatment | Precision grinding / Anti-rust coating |
| Structure Type | Straight / Flanged / Shoulder type |
| Tolerance | High precision machining standard |
| Lubrication | Oil groove / Self-lubricating optional |
| Size Range | Standard and custom sizes available |
| Service Life | Long cycle durability under high load |
