Cold Stamping Die Guide Bushing
Cold Stamping Die Guide Bushing is designed for precision alignment in stamping and punching die systems, ensuring controlled motion between guiding components during high-impact operations. It supports stable die performance under continuous production conditions, helping improve forming accuracy and operational consistency. With robust construction and reliable guiding characteristics, it is widely used in industrial metal processing environments requiring durability and precise movement control.
Product Description
Introduction
Cold Stamping Die Guide Bushing is a precision component used in cold stamping and punching die systems to maintain accurate alignment between guide pillars and die assemblies. It ensures smooth and stable guiding performance during repeated stamping cycles, helping reduce mechanical deviation and improving overall positioning accuracy. This contributes to higher stamping consistency and reliable production quality in metal forming operations.
The product is manufactured from high-quality materials such as bearing steel, alloy steel, or hardened tool steel, and undergoes heat treatment and precision grinding processes. These manufacturing steps provide excellent hardness, strong impact resistance, and stable dimensional accuracy under continuous high-load and repetitive punching conditions. The finely finished inner surface reduces friction and ensures smooth guiding performance, supporting long-term durability in demanding industrial environments.
Cold Stamping Die Guide Bushing is widely used in cold stamping dies, punching and blanking tools, progressive die systems, metal sheet forming molds, automotive stamping components, electrical hardware dies, and high-speed press equipment. It is suitable for applications requiring high precision and strong impact resistance. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can also be customized according to drawings or specific requirements, making it a reliable solution for improving die performance, extending service life, and ensuring stable production efficiency.
Specifications
| Item | Description |
|---|---|
| Product Name | Cold Stamping Die Guide Bushing |
| Material | SUJ2, GCr15, SKD11, Tool Steel |
| Hardness | HRC 58–62 |
| Surface Treatment | Precision grinding / Anti-rust coating |
| Structure Type | Straight / Flanged / Shoulder type |
| Tolerance | High precision machining standard |
| Lubrication | Oil groove / Self-lubricating optional |
| Size Range | Standard and custom sizes available |
| Service Life | Long cycle durability under impact load |
Three Key Customization Aspects, Tailored to Your Needs
Matching different customization methods to meet various requirements.
Precision Manufacturing, Excellent Quality
Enhanced Impact Resistance Performance
Material structure withstands repeated high-force stamping impacts, maintaining stable guiding accuracy and reducing deformation under extreme working conditions.
Improved Die Alignment Consistency
Ensures precise positioning between die components during high-speed stamping cycles, reducing deviation and improving forming accuracy in production processes.
Optimized Surface Fatigue Control
Heat-treated surface layer minimizes micro-crack formation, extending service life under continuous punching and repetitive mechanical stress conditions.
Stable High Load Operation Capability
Maintains structural integrity under heavy load stamping environments, supporting reliable performance in long-term industrial manufacturing applications.
Refined Service, Shortened Delivery Time
From design review to delivery, we provide dedicated one-on-one follow-up throughout the entire process.
Consultation → Provide Drawings → Design Review & Quotation → Order Processing → Quality Inspection → On-time Delivery → After-sales Follow-up
Our Advantages
Backed by over 25 years of engineering experience, our team offers comprehensive services—from customized mold design and precision machining to full-scale production—supported by a robust quality assurance system and proactive customer service. Certified under ISO9001, ISO14001, and IATF 16949, we continually strive for excellence in quality, innovation, and customer satisfaction.
Over 100,000 units in stock, with 2-hour shipment for standard products.
Implementing a three-stage inspection system—initial material check, in-process inspection, and final inspection.
Large inventory and quick turnaround, ensuring on-time delivery with 100% product inspection.
Application Range
The preferred choice across various industries.
FAQ
1. What is a Cold Stamping Die Guide Bushing used for?
It is used in cold stamping and punching die systems to guide moving components and maintain precise alignment during operation.
2. What materials are commonly used?
Common materials include bearing steel, alloy steel, and hardened tool steel for high strength and wear resistance.
3. Is it suitable for high-impact stamping applications?
Yes, it is designed to withstand repeated impact loads and continuous stamping cycles while maintaining guiding accuracy.
4. Which industries commonly use this product?
It is widely used in automotive stamping, metal forming, hardware manufacturing, electronics, and industrial tooling applications.
5. Can it be customized according to drawings?
Yes, OEM and custom manufacturing services are available for dimensions, materials, and special design requirements.
