Copper Mold Guide Bushing
Copper Mold Guide Bushing is a guiding element used in mold assemblies to support accurate positioning and smooth movement of components. It ensures stable alignment between guide pillars and mold structures during repeated operation cycles. With reliable material properties and precise machining, it helps improve motion consistency and operational efficiency in industrial molding systems where accuracy and durability are required.
Product Description
Introduction
Copper Mold Guide Bushing is a precision component used in mold systems to ensure accurate alignment between guide pillars and mold plates. It provides stable guiding support during repeated mold opening and closing cycles, helping reduce friction and maintain consistent movement accuracy. This contributes to improved molding stability and reliable performance in industrial production environments.
The product is manufactured from high-quality copper alloy or bronze materials, offering excellent wear resistance and good thermal conductivity. Through precision machining and surface finishing processes, the bushing achieves stable dimensional accuracy and smooth sliding performance. Some versions may include oil grooves or graphite features to enhance lubrication efficiency and extend service life under continuous operation.
Copper Mold Guide Bushing is widely used in injection mold bases, stamping dies, plastic mold frames, automotive components, die casting systems, and industrial machinery equipment. It is suitable for applications requiring low friction and stable long-term operation. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can also be customized according to drawings or specific requirements, making it a reliable solution for improving mold efficiency, reducing maintenance needs, and ensuring consistent production quality.
Specifications
| Item | Description |
|---|---|
| Product Name | Copper Mold Guide Bushing |
| Material | Copper alloy / Bronze (CuSn, CuZn series) |
| Hardness | HB 60–120 (depending on material) |
| Surface Treatment | Precision machining / Oil groove / Graphite optional |
| Structure Type | Straight / Flanged / Custom type |
| Tolerance | High precision machining standard |
| Lubrication | Self-lubricating / Oil groove optional |
| Size Range | Standard and custom sizes available |
| Service Life | Long service life under continuous load |
