Guangdong Guide Pillar and Bushing
Guangdong Guide Pillar and Bushing is a precision-engineered mold guiding solution designed to deliver reliable alignment and stable motion control in industrial tooling systems. Produced with advanced machining and strict tolerance control, it ensures accurate fit between components for consistent mold operation. The hardened steel construction provides strong resistance to wear and deformation under repeated cycles. Widely applied in injection molding, stamping dies, and precision manufacturing, it supports long-term durability and efficient high-volume production performance.
- Ensures Stable Mold Positioning: Maintains consistent alignment during operation.
- Reduces Sliding Resistance Effectively: Improves smooth movement efficiency.
- Increases Wear Resistance Life: Extends durability under heavy use.
- Supports High Accuracy Fit: Ensures precise component matching.
Product Description
Introduction
Guangdong Guide Pillar and Bushing is a precision mold guiding system designed to ensure accurate alignment, smooth movement, and stable performance in injection molds, stamping dies, and industrial tooling applications. It consists of a guide pillar and matching bushing that work together to maintain precise positioning between mold components, improving production consistency and reducing operational wear.
Manufactured in Guangdong using advanced CNC machining, precision grinding, heat treatment, and polishing processes, the Guide Pillar and Bushing set delivers excellent dimensional accuracy and surface quality. High-grade bearing steel such as SUJ2 or GCr15 is used to provide superior hardness, wear resistance, and long service life. The tight tolerance matching between pillar and bushing ensures low friction movement and stable guiding performance under continuous high-speed operation.
Guangdong Guide Pillar and Bushing is widely used in injection molds, progressive dies, automotive stamping tools, electronic connector molds, precision mold bases, and automation equipment. Available in various sizes, tolerances, and surface treatments, it can meet both standard mold requirements and customized engineering needs. OEM and ODM services are supported based on customer drawings and technical specifications.
Specifications
| Parameter | Specification |
|---|---|
| Product Name | Guangdong Guide Pillar and Bushing |
| Material | SUJ2 / GCr15 Bearing Steel |
| Surface Finish | Precision Ground & Polished |
| Hardness | HRC 58-62 |
| Diameter Range | Ø10 mm – Ø120 mm |
| Length Range | 80 mm – 1800 mm |
| Guiding System | Pillar & Bushing Set |
| Straightness | ≤0.003 mm/100 mm |
| Surface Treatment | Hard Chrome Optional |
| Installation Type | Press Fit / Standard Mount |
| Precision Grade | High Precision / Ultra Precision |
| Operating Condition | Continuous Industrial Use |
| Service Life | Long-Term Durability |
| Customization | OEM & ODM Available |
