Mold Base Guide Bushing
Mold Base Guide Bushing is a structural guiding component used in mold base systems to support precise movement between guiding elements. It helps ensure smooth coordination of mold parts during repeated production cycles, reducing mechanical deviation and improving assembly reliability. With durable construction and stable performance, it contributes to efficient operation and consistent quality in industrial molding applications.
Product Description
Introduction
Mold Base Guide Bushing is a precision component used in mold base assemblies to ensure accurate alignment between guide pillars and mold plates. It supports stable guiding movement during repeated opening and closing cycles, reducing friction and preventing positional deviation. This helps maintain consistent machining accuracy and improves overall production stability in industrial molding applications.
The product is manufactured from high-quality materials such as bearing steel, alloy steel, or bronze, followed by heat treatment and precision grinding processes. These processes ensure high hardness, excellent wear resistance, and stable dimensional accuracy under continuous high-load and high-speed operating conditions. The inner surface is finely finished to provide smooth sliding contact and long service life in demanding production environments.
Mold Base Guide Bushing is widely used in injection mold bases, stamping die sets, plastic mold frames, automotive mold systems, and industrial automation equipment. It is compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, and can also be customized according to drawings or specific requirements. With reliable performance and consistent guiding accuracy, it is an essential component for improving mold efficiency, reducing maintenance costs, and ensuring stable production output.
Specifications
| Item | Description |
|---|---|
| Product Name | Mold Base Guide Bushing |
| Material | SUJ2, GCr15, SKD11, Bronze |
| Hardness | HRC 58–62 |
| Surface Treatment | Precision grinding / Anti-rust coating |
| Structure Type | Straight / Flanged / Shoulder type |
| Tolerance | High precision machining standard |
| Lubrication | Oil groove / Self-lubricating optional |
| Size Range | Standard and custom sizes available |
| Service Life | Long cycle durability under high load |
