Ball Bearing Guide Bushing
Ball Bearing Guide Bushing is designed for mold systems that require precise and smooth linear movement between components. It uses rolling ball technology to replace traditional sliding contact, helping improve motion efficiency and reducing resistance during repeated operation cycles. This structure supports stable performance in high-speed production environments, ensuring consistent guiding accuracy and reliable mechanical behavior in demanding industrial applications.
Product Description
Introduction
Ball Bearing Guide Bushing is a precision motion component used in mold systems to achieve smooth and accurate linear guidance between moving parts. It replaces traditional sliding contact with rolling ball elements, significantly reducing friction and improving motion efficiency during mold opening and closing cycles. This results in higher guiding accuracy and more stable performance in high-speed industrial applications.
The structure is composed of high-strength bearing steel and a precision-machined cage that holds multiple steel balls in controlled positions. During operation, the balls roll along the guide surface, minimizing direct metal-to-metal contact. This design enhances wear resistance, reduces heat generation, and ensures consistent performance under continuous load and repetitive motion conditions. Precision grinding further improves dimensional accuracy and smooth movement.
Ball Bearing Guide Bushing is widely used in injection mold bases, stamping dies, progressive dies, plastic mold frames, automotive molds, die casting systems, and automated machinery. It is suitable for high-cycle production environments requiring low friction and high positioning accuracy. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can also be customized according to drawings or specific requirements, making it an efficient solution for improving mold performance, extending service life, and reducing maintenance costs.
Specifications
| Item | Description |
|---|---|
| Product Name | Ball Bearing Guide Bushing |
| Material | Bearing steel / Alloy steel |
| Structure Type | Ball cage type / Linear rolling type |
| Hardness | HRC 58–62 |
| Surface Treatment | Precision grinding / Anti-rust coating |
| Motion Type | Rolling contact (low friction) |
| Tolerance | High precision machining standard |
| Size Range | Standard and custom sizes available |
| Service Life | Long life under high-speed operation |
