Graphite Mold Guide Bushing
Graphite Mold Guide Bushing is designed for mold systems requiring stable guiding performance without external lubrication. It ensures accurate movement between mold components while maintaining smooth operation during continuous working cycles. The embedded graphite structure provides consistent lubrication support, helping reduce friction and improving operational reliability in demanding industrial environments where maintenance efficiency is important.
Product Description
Introduction
Graphite Mold Guide Bushing is a self-lubricating component used in mold systems to ensure precise alignment and smooth movement between guide pillars and mold plates. It helps maintain stable guiding performance during repeated operation cycles, reducing friction and improving positioning accuracy. This contributes to consistent molding quality and reliable performance in industrial production environments.
The product is manufactured using high-strength bronze combined with embedded graphite plugs, which provide continuous lubrication during operation without the need for external oil or grease. This structure enhances wear resistance, reduces maintenance requirements, and ensures stable performance under dry running and high-load conditions. Precision machining further improves dimensional accuracy and surface smoothness for long-term durability.
Graphite Mold Guide Bushing is widely used in injection mold bases, stamping dies, plastic mold frames, die casting systems, automotive molds, and industrial machinery equipment. It is suitable for applications where lubrication is difficult or maintenance access is limited. Compatible with international standards such as MISUMI, HASCO, DME, DIN, and ISO, it can also be customized according to drawings or specific requirements, making it an efficient and maintenance-free solution for improving mold performance and operational stability.
Specifications
| Item | Description |
|---|---|
| Product Name | Graphite Mold Guide Bushing |
| Material | Bronze (CuSn8 / CuAl10Ni5Fe4) |
| Lubrication Type | Solid graphite plug self-lubrication |
| Structure Type | Straight / Flanged / Shoulder |
| Hardness | HB 70–120 (depending on alloy) |
| Surface Finish | Precision machined with graphite inserts |
| Working Condition | Dry running, no external lubrication required |
| Load Capacity | High load and continuous operation suitable |
| Custom Size | Available according to drawings |
